RMWH RECTANGULAR PERMANENT MAGNETIC MICROPITCH CHUCK
Product details：
RMWH RECTANGULAR PERMANENT MAGNETIC MICROPITCH CHUCK
［Application］
Suitable for grinding thin, thick and small workpieces.
［Features］
●Extremely low profile, 45 mm for small to medium sizes and 50 mm for large sizes and light weight.
●A wide attractive area on the chuck work face, allowing the corners to be utilized.
●The magnetic force ON-OFF handle can be operated lightly thanks to a special slide design. The side insert type used allows the handle to be detached when it is not used.
●A micropitch type having very fine pole-to-pole pitches. This design provides effective holding power not only on thick workpieces but also on thin and small workpieces.
●Drip-proof specification. (Not usable in liquid) ※ For use in liquid, please use Model RMWH-ED.
|
